Metaltech Self-Supporting Guardrail System - Stackable
Metaltech Self-Supporting Guardrail System - Stackable

Metaltech Self-Supporting Guardrail System - Stackable

Warranty 10 years
Standard: CNESST/CBNC/OSHA

A self-supporting guardrail with stackable bases, for efficiently securing tight spaces with no drilling.

Select your reference
+
-
Metaltech Self-Supporting Guardrail System - Stackable

Advantages and strengths

Installed directly on the roof, with no additional membrane. Moulded handle for easy transport. Ultra-light for easy assembly.

Technical characteristics

Reference Quantity Quote
Ref.
+
-
Reference :
Quantity :
+
-

Use

Installez le système Empilable pour sécuriser rapidement un espace restreint, delimiter un puits de lumière ou une trappe d'accès au toit, ou protéger une zone lors du déneigement ou de travaux de maintenance et d'inspection.

Choisissez le kit M-MTGE120K pour une installation linéaire de 10 pi, ou le kit M-MTGH6060K, conçu spécifiquement pour entourer un puits de lumière de 5 pi x 5 pi. Les deux kits s'installent sans soudure ni perçage, avec peu d'outils.

Technical description

Recycled rubber


Patented design


Aluminium 6061-T6


Pipes posts – outer diameter: 0.05 m (1.9")


Minimum length: 6 m (240")


Height: 1 m (39")


Max. distance between the posts: 3 m (120")


Ceiling to floor return: at each end, at every 1 m (40") on parapet-free roofs


Counterweight: 22.70 kg (50 lb/base)


Fittings - material: galvanised steel


Hardware: stainless steel


Tightening torque : 13.60 kg (30 lb/pi) 9 kg (CL201: 20 lb/pi)


Compatible with the VSS SafetyLine line of products
