SELF-SUPPORTING GUARDRAIL FOR ROOF ACCESS LADDERS
SELF-SUPPORTING GUARDRAIL FOR ROOF ACCESS LADDERS

SELF-SUPPORTING GUARDRAIL FOR ROOF ACCESS LADDERS

Improves the safety around these very common access points.

Select your reference
+
-
SELF-SUPPORTING GUARDRAIL FOR ROOF ACCESS LADDERS

Advantages and strengths

Quick and easy assembly. Weatherproof.

Technical characteristics

Reference Quantity Quote
Ref.
+
-
Reference :
Quantity :
+
-

Use

The recycled rubber base provides the best adhesion without any additional membrane.

No damage to the roof, because it is 100% self-supporting.

Aluminium preventing the peeling of paint.

Best resistance to rust and deterioration caused by the rain, temperature changes and acid environments.

Moulded handle for easy transport.

Installed on roofs with or without parapet.

10 years of warranty.

Technical description

Recycled rubber


Pipes & posts:


Aluminium 6061-T6


Outer diameter: 25.40 mm (1.9")


Length: 30.50 cm (12'6"/side)


Height: 1 m (42")


Width: 1.90 m (75")


Opening of the security barrier: 0.50 m - 0.66 m (22.75" - 26.50") (optional)


Counterweight: 22,70 kg (50 lb/base)


Fittings - material: galvanised steel


Hardware: stainless steel


Tightening torque: 13.60 kg (30 lb/pi) (CL201: 20lb/pi)
